Air-Fluid All Metal Push in Fittings Male BSPP
Home > Products > Other Hand Tools > Air-Fluid All Metal Push in Fittings Male BSPP

Air-Fluid All Metal Push in Fittings Male BSPP


  • Air-Fluid All Metal Push in Fittings Male BSPP
  • Air-Fluid All Metal Push in Fittings Male BSPP
  • Air-Fluid All Metal Push in Fittings Male BSPP
  • Air-Fluid All Metal Push in Fittings Male BSPP
  • Air-Fluid All Metal Push in Fittings Male BSPP

Air-Fluid All Metal Push in Fittings Male BSPP

    Payment Type: L/C,T/T,paypal
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 300 Set/Sets
    Delivery Time: 7 Days
    Packaging: PE Bag/ Carton /Pallet
    Productivity: 100,000
    Brand: Air-Fluid
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: 5000
    Certificate: ISO9001

Basic Info

Model No.: AJPC08-G1/4

Product Description

Cixi Air-Fluid AJPC08-G1/4 Metal Pneumatic Push in Fitting, Male Studs BSPP .

Brand Name: Air-Fluid ,Material: Nickel Plated Brass ,Max Working Pressure :1000psi, O-Ring Material : NBR ,Thread Type :BSPP , Item Shape :Straight Male Connectors, Temp Range -20 To 100 Deg , Weight : 18.70g,Height: 24.00mm, Thread Length: 8.00mm, Nickel Thickness: 10 um, Package Quantity 50 Pcs .


BSPP Thread Introductions : The British Standard Pipe Parallel (BSPP Threads )have the same diameter from end to end ,A parallel thread typically seals with use of an o-ring or Back Washer to seal the fittings ,no use of Anaerobe. The sealing ring (O-ring) can be easily replaced if it is damaged or hard-worn with time. Connection and disconnection of the tube can be repeated and can be performed using one hand , no other tools required .


Thread Connection : Range from BSPP 1/8" to 1/2"

Push-in Connection: Range from Inch Size 5/32" to 1/2" OD & Metric Size 04mm to 16 MM

Configurations Includes: Straight , Elbow , Branch Tee ,Run Tee, Long Leg Male Elbow and Speed Control Valve .


Air-Fluid Products> Pneumatic Metal Push in Fittings >Bulkhead Union Connector Push In Fitting>Cross Union Connector Push In Fitting>Elbow Union Connector Push In Fitting>Tee Union Connector Push In Fitting>Y Union Connector Push In Fitting>Plug Connector Push In Fitting
>Female Connector Push In Fitting.
11



Ningbo Air-Fluid is the Premier and Leading manufacturer for All Metal Push in Fittings ,Nickel-Plated Brass Push-to-Connect Fittings ,Brass Pipe Fittings ,Misting Cooling Systems Fittings and Pneumatic Fittings in China(mainland).

Pneumatic Fittings, Air Flow Control Valve , Air Fittings, Push To Connect Fittings, Nickel Plated Brass Push in Fittings with O-ring (BSPP, G),Push In Fittings, One Touch Tube Fittings, Air Fitting, Air Line Fittings, DOT Air Brake Fittings, DOT Brass Fittings, Quick Coupler , Air Blow Gun, Air Tubing, Air Silencer.Nickel Plated Brass Push in Fittings (PT, R, BSPT, NPT),One Touch Tube Fittings with O-ring (BSPP, G),Pneumatic Fittings, Push in Fittings (PT, R, BSPT, NPT),Check Valve ,Rapid Joint Fittings ,DOT Push in Fittings ,Brass Pneumatic Fittings,316 Stainless Steel Push in Fittings, Standard Steel Push in Fittings. Standard Pipe Fittings & Accessories .Air Blow Guns ,Pneumatic Tube ,Push In Fittings (BSPT, NPT) , Push To Connect Fittings (BSPP, G) , Inch Composite Push In Fittings ,Brass Push In Air Fittings (R, NPT) ,Brass Push In Air Fittngs (BSPP, G) , Stainless Steel Push In Fittings , Compact One Touch Fittings , Air Flow Control Valves , Hand (Shut-off) Valves , Check Valves , Schrader Inflation Valves , Mini Ball Valves , Stop Fittings .

Air-Fluid achieved the Quality Assurance Systems according to the ISO 9001 and Air-Fluid updated the Quality Management System to the ISO 9001:2000 Standards.


In terms of customer service, Air-Fluid plays a progressive and active role in providing the customers with the best after-sales service , competitive prices, cost-effectiveness, and prompt delivery schedule meet their demands.

We cordially invite you to browse our website for your interested products and technical information and wish To enjoy peace & prosperity business relationship with you together.
